Specification Video/Audio Input
Two-way audio input:1-ch, RCA (2.0 Vp-p, 1kΩ)
IP video input:4-ch
Network
Remote connection:128
Incoming bandwidth:40Mbps
Outgoing bandwidth:80Mbps
Video/Audio Output
HDMI Output:1-ch, resolution: 4K(3840*2160)/60Hz, 4K(3840*2160)/30Hz, 1920*1080P/60Hz, 1600*1200/60Hz, 1280*1024/60Hz, 1280*720/60Hz, 1024*768/60Hz
Recording Resolution:8MP/6MP/5MP/4MP/3MP/1080p/UXGA/720p/VGA/4CIF/DCIF/2CIF/CIF/QCIF
Audio Output:1-ch, RCA (Linear, 1kΩ)
Synchronous Playback:4-ch
VGA Output:1-ch, resolution: 1920*1080P/60Hz, 1280*1024/60Hz, 1280*720/60Hz, 1024*768/60Hz
Decoding
Capability:4-ch@1080P
Live view / Playback:8MP/6MP/5MP/4MP/3MP/1080p/UXGA/720p/VGA/4CIF/DCIF/2CIF/CIF/QCIF
Hard Disk
SATA:1 SATA interfaces for 2 HDDs
Capacity:Up to 6TB capacity for each HDD
External Interface
Network Interface:1RJ-45 10/100/1000Mbps self-adaptive Ethernet interface
Serial Interface:RS-232
USB Interface: 2× USB 2.0
POE
Supported Standard:AF and AT
Interface:4 independent 10/100 Mbps PoE Ethernet interfaces
Max. Power:200W
General
Power Supply:100 to 240 VAC, 50 to 60 Hz
Consumption(without hard disk and POE):≤15 W
Working Temperature:-10 oC ~ +55 oC (+14 oF~ + 131 oF)
Working Humidity:10 % ~ 90 %
Chassis:380 chassis
Dimensions:380 × 290 ×45 mm (15.0"× 11.4" × 1.8")
Weight(without HDD):≤ 3 Kg (6.6 lb)
