Description
◆Camera
＊Image Sensor:1/1.8" Progressive Scan CMOS
＊Signal System:PAL/NTSC
＊Min. Illumination:0.0014 Lux @ (F1.0, AGC ON), 0 Lux with Light
＊Shutter time:1/3 s to 1/100,000 s
＊Slow shutter:Support
＊Lens:2.8 mm, horizontal: 109°, vertical: 55°, diagonal: 138°
＊Lens Mount:M16
＊Day& Night:Auto
＊Wide Dynamic Range:120 dB
＊Digital noise reduction:3D DNR
◆Compression Standard
＊Video Compression:H.265+/H.265/H.264+/H.264/MJPEG
＊Video bit rate:32Kbps~16Mbps
◆Image
＊Max. Image Resolution:2688 x 1520 @ 30fps
＊Image Enhancement:BLC/3D DNR/HLC/ROI
＊Image Settings:Saturation, brightness, contrast, sharpness, AGC,white balance adjustable by client software or web browser
＊ROI:Support 1 fixed region for main stream and sub-stream separately
◆Network
＊Network Storage:microSD/SDHC/SDXC card (128G), local storage and NAS (NFS,SMB/CIFS), ANR
＊General Function:One-key reset, anti-flicker, three streams, heartbeat, mirror, password protection, privacy mask, watermark, IP address filter
＊System Compatibility:ONVIF (Profile S, Profile G),ISAPI
◆Interface
＊On-board storage:Built-in Micro SD/SDHC/SDXC slot, up to 128 GB
＊Reset Button:Yes
◆Smart Feature-set
＊Behavior Analysis:Line crossing detection, intrusion detection, unattended baggage detection, object removal detection
＊Line Crossing Detection:Cross a pre-defined virtual line
＊Intrusion Detection:Enter and loiter in a pre-defined virtual region
＊Unattended Baggage:Objects left over in the pre-defined region such as the baggage, purse, dangerous materials
＊Object Removal:Objects removed from the pre-defined region, such as the exhibits on display.
◆General
＊Operating Conditions:-30 °C ~ 60 °C (-22 °F ~ 140 °F)Humidity 95% or less (non-condensing)
＊Power Supply:12 VDC ± 25%, 5.5 mm coaxial power plug ,PoE (802.3af, class 3)
