Description
❤Camera
Image Sensor: 1/3" Progressive Scan CMOS
Min. Illumination: Color: 0.01 Lux @ (F1.2, AGC ON), 0.018 Lux @ (F1.6, AGCON), 0 Lux with IR
Lens: 2.8 mm @ F1.6: horizontal FOV: 103°, vertical FOV: 58°, diagonal FOV:123°
Lens Mount: M12
Adjustment Range: Pan: 0° to 360°, tilt: 0° to 75°, rotate: 0° to 360°
Day& Night: IR cut filter with auto switch
Wide Dynamic Range: 120 dB
❤Compression Standard
Video Compression: H.265+/H.265/H.264+/H.264/MJPEG
Video bit rate: 256Kbps~16Mbps
❤Image
Max. Image Resolution: 2688 × 1520
Frame Rate: 50Hz:25fps (2688 × 1520, 2560 × 1440, 2304 × 1296, 1920 × 1080), 60Hz:30fps (2688 × 1520, 2560 × 1440, 2304 × 1296, 1920 × 1080)
Sub Stream: 50Hz: 25fps (640 × 480, 640 × 360, 320 × 240), 60Hz: 30fps (640 ×480, 640 × 360, 320 × 240)
❤Network
Network Storage: microSD/SDHC/SDXC card (128G), local storage and NAS(NFS,SMB/CIFS), ANR
Protocols: TCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP,PPPoE, NTP, UPnP?, SMTP, SNMP, IGMP, 802.1X, QoS, IPv6, Bonjour
System Compatibility: ONVIF (Profile S, Profile G),ISAPI
❤General
Operating Conditions: -30 °C ~ 60 °C (-22 °F ~ 140 °F), Humidity 95% or less(non-condensing)
Power Supply: 12 VDC ± 25%, PoE (802.3af Class3)
Power Consumption: 12 VDC, 0.5A, max. 6W, PoE (802.3af, 37V to 57V), 0.2A to0.1A, max. 7.5W
Weather Proof: IP67
IR Range: Up to 30m
Dimensions: Camera: Φ 127.3 × 95.9 mm (Φ 5.0" × 3.4")
Weight: Camera: Approx. 610 g (1.3 lb.)
