Camera
Image Sensor:1/3" 4MP Progressive Scan CMOS
Min. Illumination: Color: 0.018 lux @ (f/1.6, AGC on)
Shutter time:1/3 s to 1/100,000 s
Lens:2.8mm,@ F1.6 angle of view: 103°(2.8mm)
Day& Night:IR cut filter with auto switch
Wide Dynamic Range:120 dB
Digital noise reduction:3D DNR

Compression Standard
Video Compression:H.265+/H.265/H.264+/H.264/MJPEG
Video bit rate: 256 Kbps to 16 Mbps
Triple Streams:Yes

Max. Image Resolution:2688 × 1520 @ 30fps
Image Settings:Rotate Mode, Saturation, Brightness, Contrast, Sharpness adjustable by client software or web browser
BLC:Yes, zone configurable

Network
Network Storage: Supports microSD/SDHC/SDXC card (128 GB), local storage, NAS (NFS,SMB/CIFS),and ANR
Alarm Trigger:Face Detection,Line Crossing, Intrusion Detection, Motion detection, Dynamic analysis, Tampering alarm, Network disconnect , IP address conflict, Storage exception
System Compatibility:ONVIF (Profile S, Profile G),ISAPI
Client: iVMS-4200, Hik-Connect

Interface
Communication Interface:1 RJ45 10M / 100M Ethernet interface
On-board storage:Built-in Micro SD/SDHC/SDXC slot, up to 128 GB
Reset Button:Yes

General
Operating Conditions:-30 °C ~ 60 °C (-22 °F ~ 140 °F)
Humidity 95% or less (non-condensing)
Power Supply:12 VDC ± 25%, PoE (802.3af Class3)
Power Consumption:Max. 5W
Impact Protection:IK10
Weather Proof:IP67
IR Range:Up to 30m
Dimensions:Φ111 × 82 (4.4" × 3.2")
Weight:610g (1.3lbs)
