AMPLIFIER

Adjustable 12db high pass/low pass crossovers
Chipset: full range class d using ir (international rectifier) control chips
PCB board: 4 layer conformal coated
Water resistance: ipx6
Crossover points: 40 hz to 500hz
THD: .07 percent
S/N Ratio (1 watt @ 4 ohms) : > 90db
Gain Range: .2 volts - 5 volts
Freq Range: 20 hz - 20 khz
Fuse Holder: ip68 rated
Fusing: 40 amp (dual 20 amp fuses)
W 7.519in/191mm
H 1.54in/39.2mm
D 4.18in/106.4mm
60 watts RMS x 4 Channels at 4 ohms
90 watts RMS x 4 Channels at 2 ohms
180 watts RMS x 2 Channels at 4 ohms

SPEAKERS
Power Handling: Peak: 600 watts / RMS: 200 watts per pair
Recommended Power Range: 10 - 100 watts RMS per channel
Features EVC (Extended Voice Coil) technology
Polypropylene mid-woofer cone material
Polyester foam speaker surround
1/2" Polyether imide (PEI) balanced dome tweeter
Neodymium magnet motor structure
Stamped steel frame basket
Top-mount Depth: 3/8"
Cutout Dimensions: 4-13/16"
4 ohms impedance
Frequency Response: 40 - 20,000 Hz
Sensitivity: 90dB

BLUETOOTH CONTROLLER

One knob does all control features (track/volume/power/source/play/pause/pairing)
Complete wireless connection via Bluetooth 4.0
Play music from any media player with 3.5mm auxiliary output
Built-in line driver for 3x voltage output
Remembers paired devices and automatically reconnects in connected order when device is present
Patent pending single wire controller connection directly to a Metra PowerSports Amplifier
Fits Industry Standard Opening: 1.45in X .83in

SPEAKER ADAPTERS

6-1/2" - 6-3/4" Speaker Adapter Plate
For 1998-2013 Harley Davidson Touring vehicles
Designed and manufactured with precision tolerances
Gapless fit between the speaker and the kit
