Image Sensor: 1/2.5'' CMOS Aptina MT9P001
Pixel Size: 2.2μm x 2.2μm
Resolution: 2 MP 2592(H) X 1944(V)
Shutter Type: Electronic rolling shutter
Focus: Manually adjustable
Focusing Range: 20mm to Infinity
Protocol & Connection: Plug-&-Play (UVC compliant)
Frame Rate:
320X240 MJPEG @30fps, 640X480 MJPEG @30fps, 800X600 MJPEG @30fps, 1024X768 MJPEG @30fps, 1280X960 MJPEG @10fps, 1280X1024 MJPEG @10fps, 1280x1024 MJPEG @10fps, 1600x1200 MJPEG @15fps, 2048x1536 MJPEG @15fps, 2592x1944 MJPEG @15fps.
YUV2 @ 30fps, 640X480 YUV2 @ 30fps, 800X600 YUV2 @ 20fps, 1024X768 YUV2 @ 10fps, 1280X960 YUV2 @ 10fps, 1280X1024 YUV2 @ 10fps, 1280x1024 YUV2 @ 10fps, 1600x1200 YUV2 @ 5fps, 2048x1536 YUV2 @ 4fps, 2592x1944 YUV2 @ 2fps.
Minimum Illumination: 0.5Lux
Lens: Default 90 degree 3.6mm lens with IR-Cut Filter (IR Filter) default at 650nm, custom options at 850nm or 940nm. For other Custom options, please contact us.
Night vision: No IR night vision, if needed, please contact us for a different IR lens and IR illumination options.
Controllable Features: Brightness, Contrast, Saturation, Hue, Sharpness, Gamma, White balance, Backlight Contrast, Exposure.
Power Socket: 4P PH 2.0mm socket, USB BUS Power.
Cable Length: Default 4ft (1.2M) (optional 2M or others upon request).
Supported OS: Win XP/Vista/Win7/Win8/Win10, Linux with UVC (linux-2.6.26 or later), MAC-OS X 10.4.8 or later, Wince with UVC, Android 4.0 or higher with UVC.
Power Consumption: DC5V (±5%), 150~200mA.
Operating Temp.: -4°F~167°F (-20°C~+75°C).
Storage Temp.: -40°F~185°F (-40°C~+125°C)
Dimension: 38mmx 38mm (Mount compatible with 32 x 32mm)
