Camera
Image Sensor:1/2.7" 5Megapixel progressive scan CMOS
Effective Pixels:2592(H)x1944(V),5 Megapixels
Scanning System:Progressive
Electronic Shutter Speed:Auto/Manual, 1/3(4)~1/100000s
Minimum Illumination:Color:0.02Lux/F1.6( Color,1/3s,30IRE); 0.2Lux/1.6( Color,1/30s,30IRE); 0.05Lux/F1.6( B/W,1/3s,30IRE); 0.5Lux/1.6( B/W,1/30s,30IRE)
IR Distance:N/A;
IR On/Off Control:N/A;
IR LEDs:N/A Lens
Focal Length:1.4mm
Max. Aperture:F1.6
Angle of View:H:180°~180°
DORI Distance:Lens(1.4mm),Detect(92ft),Observe(36ft),Recognize(20ft),Identify(10ft)
Intelligence
Advanced Intelligent Functions:Tripwire ,Intrusion,Heat map
Video
Compression:H.265+/H.265/H.264+/H.264
Streaming Capability:3 Streams
Resolution:5M(2592×1944)/3M(2048×1536)/UXGA(1600×1200)/1.3M(1280×960)/D1(704×576/704×480)/CIF(352×288/352×240)
Frame Rate:Main Stream:5M(1~25fps);Sub Stream: D1(1~25/30fps)
Bit Rate Control:CBR/VBR
Day/Night:Electronic
BLC Mode;BLC/HLC/WDR(120dB)
White Balance:Auto/Natural/Street Lamp/Outdoor/Manual
Gain Control:Auto/Manual
Noise Reduction:3D DNR
Motion Detection:Off/On(4 Zone,Rectangle)
Region of Interest:Off/On(4 Zone)
Digital Zoom:16x
Mirror:Off/On
Privacy Masking:Off/On(4 Area,Rectangle)
Audio
G.711a/ G.711Mu/ AAC/ G.726
Network
Ethernet:RJ-45(10/100Base-T)
Protocol:HTTP;HTTPs;TCP;ARP;RTSP;RTP;UDP;SMTP;FTP;DHCP;DNS;DDNS;PPPOE;IPv4/v6;QoS;UPnP;NTP;Bonjour;802.1x; Multicast; ICMP;IGMP; SNMP
Interoperability:ONVIF,PSIA,CGI
Streaming Method:Unicast/Multicast
Max. User Access:10 Users /20 Users
Edge Storage:NAS (Network Attached Storage),Local PC for instant recording,Micro SD card 128GB
Interface
Audio Interface:Built-in Mic
Construction
Power Supply:DC12V, PoE (802.3af)(Class 0)
Power Consumption:<3.4W
