Camera
Image Sensor:|1/3" Progressive Scan CMOS
Min. Illumination:|Color: 0.028 lux @ (ƒ/2.0, AGC on); B/W: 0 lux with IR
Shutter time:|1/3 s to 1/10,000 s
Lens:|2.8 mm, angle of view: 106°
Lens Mount:|M12
Day& Night:|IR cut filter with auto switch
Compression Standard
Video Compression:|H.265+/H.265/H.264+/H.264/MJPEG
Video bit rate:|32Kbps~16Mbps
Audio Compression:|G.711/G.722.1/G.726/MP2L2
Max. Image Resolution:|2560×1920
Frame Rate:|20fps (2560×1920), 25fps (2048x1536), 25fps(1920×1080), 25fps(1280×720)
Network
Network Storage:|NAS (Support NFS,SMB/CIFS), ANR
Protocols:|TCP/IP, UDP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, PPPoE, NTP, UPnP, SMTP, SNMP, IGMP,802.1X, QoS, IPv6, Bonjour
Security:|User Authentication, Watermark, IP address filtering, anonymous access, flickerless, heartbeat, video mask
System Compatibility:|ONVIF, PSIA, CGI, ISAPI
Interface
Audio Input:|1channel
Audio Output:|1 channel
Communication Interface:|
1 RJ45 10M / 100M Ethernet interface
Alarm:|1 alarm input, 1 alarm output On-board storage:|Built-in Micro SD/SDHC/SDXC slot, up to 128 GB
General
Operating Conditions:|-30 °C ~ 60 °C (-22 °F ~ 140 °F)
Power Supply:|12 VDC , PoE (802.3af)
Impact Protection:|IK10
Weather Proof:|IP67
IR Range:|30 meters
Dimensions:|Φ111 mm × 82 mm (4.4" × 3.2")
Weight:|500 g (1.1 lbs)
