Camera
Image Sensor: | 1/3" Progressive Scan CMOS
Min. Illumination: | 0.01Lux @(F1.2,AGC ON), 0.014 Lux @(F1.4,AGC ON), 0 Lux with IR
Shutter time: | 1/3 s ~ 1/100,000 s
Slow shutter: | Support
Lens: | 2.8 - 12 mm @ F1.4, angle of view: 112°~33.8°
Lens Mount: | φ14
Adjustment Range: | Pan:0° - 355°, Tilt: 0° - 75°, Rotation: 0° - 355°
Day& Night: | IR cut filter with auto switch
Wide Dynamic Range: | 120 dB
Digital noise reduction: | 3D DNR
Compression Standard
Video Compression: | H.264/MJPEG/H.264+
H.264 code profile: | Main Profile
Video bit rate: | 32Kbps~16Mbps
Audio Compression: | -S: G.711/G.722.1/G.726/MP2L2
Max. Image Resolution: | 2688 × 1520
Image Enhancement: | BLC/3D DNR/ROI
Image Settings: | Rotate Mode, Saturation, Brightness, Contrast, Sharpness
adjustable by client software or web browser
Day/Night Switch: | Auto/Schedule/Triggered by Alarm In
Network
Network Storage: | Micro SD/SDHC/SDXC card with ANR (up to 128G), NAS (Support
NFS, SMB/CIFS)
General Function: | One-key reset, Anti-Flicker, heartbeat, mirror, password protection,
privacy
mask, Watermark, IP address filtering
System Compatibility: | ONVIF (Profile S, Profile G), PSIA, CGI, ISAPI
Interface
Communication Interface: | 1 RJ45 10M / 100M Ethernet interface General
Operating Conditions: | -30 °C ~ 60 °C (-22 °F ~ 140 °F)
Humidity 95% or less (non-condensing)
Power Supply: | 12 VDC ± 25%, PoE (802.3af Class3)
Power Consumption: | Max. 5.5 W
Impact Protection: | IEC60068-2-75Eh, 50J; EN50102, IK10
Weather Proof: | IP67
IR Range: | Up to 30m
Dimensions: | Φ 140 × 99.9 mm (Φ 5.51" × 3.94")
Weight: | 1000g (2.20lbs)
NOTE：: | * "-S" series support 1-ch audio I/O and 1-ch alarm I/O
