Camera
Image Sensor:1/2.5" 8Megapixel progressive scan CMOS
Effective Pixels;3840(H)x2160(V)
Electronic Shutter Speed:Auto/Manual,1/3(4)~1/100000s
S/N Ratio:More than 50dB
IR Distance:Distance up to 30m (98ft)
IR LEDs:18

Lens
Focal Length:2.8mm
Max. Aperture:F1.6
Angle of View:H:112°,V:69°
Close Focus Distance:0.9m

Intelligence
IVS:Tripwire,Intrusion,Object Abandoned/Missing
Advanced Intelligent Functions:Face Detection

Video
Compression:H.265+/H.265/H.264+/H.264
Streaming Capability:3 Streams
Resolution:4K(3840×2160)/6M(3072×2048)/5M(2560×1920)/3M(2048x1536)/3M(2304×1296)/1080P(1920×1080)/1.3M(1280x960)/720P(1280×720)/D1(704×576/704×480) /VGA(640×480)/CIF(352×288/352×240)
Frame Rate:Main
Stream:4K(1~15fps)/3M(1~25/30fps);Sub:D1(1~25/30fps);Third:1080P(1~25/30fps)
Bit Rate Control:CBR/VBR
Day/Night:Auto(ICR)/Color/B/W
BLC Mode;BLC/HLC/WDR(120dB)
White Balance:Auto/Natural/Street Lamp/Outdoor/Manual
Noise Reduction:3D DNR
Motion Detetion:4 Zone,Rectangle
Region of Interest:4 Zone
Smart IR:Support
Digital Zoom:16x
Flip:0°/90°/180°/270°
Mirror:Off/On
Privacy Masking:4 Area,Rectangle

Audio
Compression:G.711a/G.711Mu/AAC/G.726

Network
Ethernet:RJ-45 (10/100Base-T)
Protocol:HTTP;HTTPs;TCP;ARP;RTSP;RTP;UDP;SMTP;FTP;DHCP;DNS;DDNS;PPPOE;IPv4/v6;QoS;UPnP;NTP;Bonjour;802.1x;Multicast;ICMP;IGMP;SNMP
Interoperability:ONVIF, PSIA, CGI
Max. User Access:10/20
Edge Storage:NAS;Local PC for instant recording;Mirco SD card 128GB
Management Software:Smart PSS, DSS, Easy4ip

Interface
Audio Interface:1/1 channel In/Out
Alarm:1 channel In: 5mA 5VDC; 1 channel Out: 300mA 12VDC

Construction
Power Supply:DC12V, PoE (802.3af)
Power Consumption:<5.5W
Casing:Metal
