Hpe 8 Sff Drive Backplane Cage Kit

review and follow precautions press the power button to put the her in standby disconnect the power cord from the server drivers from the eight SFF drive cage remove the access panel the smart storage battery remove any fans that might impede disconnecting cables from the back planes disconnect the cables from the two SFF backplane disconnect the cables from the eight SFF backplane you slide the smart storage battery clip off of the retaining tab on the chassis pan and remove pull up on the retaining clip then slide the eight s FF back plane toward the inside of the chassis about 1/4 inch point 635 centimeters move the back plane away from the drive cage and lift it out of the chassis [Music] align the notches on the bottom edge of the eight SFF backplane with the guide pins on the chassis Pam place the backplane against the drive cage and slide it toward the outside of the chassis abou
