Description
This heat shrink tube is best for wire connection, solder joint protection, connectors sealing, group lines marking, resistance electric capacity insulation protection etc.
Features:
- Corrosion Resistance
- Good Electrical Insulation
- High-strength Toughness
- High Temperature Resistant
- Waterproof Resistant
- Long Service Life
How To Use:
1. CHOOSE THE RIGHT SIZE TUBE. Measure the diameter of wire/cable you want to wrap, make sure the diameter is equal to the size of heat shrink tube after shrinked, because the tube will shrink up to 1/2 of original diameter after heating.
2. WRAP THE WIRE WITH THE TUBE. Cut out the length you need, wrap the wire with the tube, use a lighter, hair dryer or heat gun to heat the tube.
3. HEAT THE TUBE UNTIL THE WIRE IS WRAPPED TIGHTLY.
NOTES:
-PLEASE BE CAREFUL WHILE USING LIGHTER OR HEAT GUN.
-PLEASE STAY AWAY FROM WHILE HEATING.
Specifications:
Material: Polyethylene
Shrinkage Ratio: 2:1 ( will maximum shrink to 1/2 of its supplied diameter )
Minimum Shrinkage Temp: +70 Degree Celsius
Full Shrinkage Temp: +125 Degree Celsius maximum
Operating Temperature:-55 to 125 Degree Celsius
Rated voltage: 1000V
Dielectric strength: 1 KV
Flammability: VW-1, Flame Retardant
Item Shape: Round/Flat
