Description
Specification
Model : DS-2CD2542FWD-IS
Image :Sensor
Shape : Dome
Sensor : CMOS
Sensor Size : 1/3 Inch Color CMOS Sensor
Effective Pixels : 4.0 MP
Lens (mm) :2.8mm, 4mm, 6mm
Lens + :IR-cut
Minimum Illumination (Lux) : 0.01Lux @ (F1.2, AGC ON), 0 Lux with IR
Listing Date : 02/28/2017
General Specification
Languages : Simplified Chinese, Japanese, Other, Russian, Korean, Spanish, Italian, German, Portuguese, French, Traditional Chinese, English
Video Image/Audio Setting
Compression : H.264
Video Adjustment: Auto Backlight Compensation
Audio Output : Built-in Speaker
Audio Input : Built-in Mic
Communication&Interface
Connection Mode : POE
Network Interface : RJ-45 10/100Mb self-adaptable Ethernet slot
Supported Protocol : TCP/IP, PPPoE, UPNP, DDNS, HTTP, SMTP, DNS, DHCP, FTP
IP Mode :Static IP address, Dynamic IP address
DDNS (Free) :Yes
Physical/Environment
Home :Garage, Baby Room
Business :School, Warehouse, Store, Office
Environment : Indoor
Power Consumption (W) : 5
Operate Temperature (??) : -30 ~ 60
Humidity (%) RH : 95
Size (L x H x W, mm) : 99.3*96.7*52.8
Net Weight(kg) 0.7
System Requirment
Supported Mobile Systems : Android, iPhone OS
Supported Operating Systems : Microsoft Windows 98, Microsoft Windows 10
Supported Browser :Firefox, IE
Additional Features
IR Night Vision Distance (m) : 10
Voice call : Two-Way Audio
Storage : TF Card
Maximum SD Card Support (GB) : 128
Update Firmware : Yes
Features :PoE, Motion Detection, Waterproof, Plug and play, Remote Access, Dual Stream
General
What's in the box :Screew, English User manual
