Description
Camera
Image Sensor: 1/2.9" 6Megapixel progressive scan CMOS
Effective Pixels: 3072(H) x 2048(V)
Scanning System:Progressive
Electronic Shutter Speed Auto/Manual, 1/3(4)~1/10000s
Min. Illumination: 0.01Lux/F2.0 (Color), 0Lux/F2.0(IR on)
S/N Ratio More than 50dB
Adjust the angle: Level : 0 ° ~ 360 °, Vertical : 0 ° ~ 65 °
Camera Features
Max. IR LEDs Length:50m
Day/Night:Auto(ICR) / Color / B/W
Backlight Compensation BLC / HLC / DWDR White Balance Auto/Manual
Gain Control:Auto/Manual
Noise Reduction:3D
Privacy Masking:Up to 4 areas
Lens
Fixed lens:3.6mm
Max Aperture: F2.0
Angle of View: H: 110°/81°/55°
Lens Type :Fixed lens
Mount Type:Board-in Type
Video
Compression:H.265;H.264;H.264H;H.264B;MJPEG Frame Rate;Main Stream
Resolution:50HZ:Main (3072×2048@20fps),Sub(704× 576@20fps),Third(1280×720@6fps)
Main(2592×1944@25fps),Sub(704×576@25fps),Third(1280×720@4fps)
60Hz: Main(3072×2048@20fps),Sub(704×480@20fps),Third(1280×720@7fps)
Main(2688×1520@30fps),Sub(704×480@30fps),Third(1280×720@10fps)
Audio:built-in Mic
Main Stream: 4M(1~20fps)/3M(1~25/30fps)
Sub Stream: D1/CIF(1 ~ 25/30fps)
Third Stream: 720P(1-5/8fps)(WDR on) & 720P(1-18/2fps)(WDR off)
Network
Ethernet RJ-45 (10/100Base-T)
Protocol IPv4/IPv6, HTTP, HTTPS, SSL, TCP/IP, UDP, UPnP, ICMP, IGMP, SNMP,
RTSP, RTP, SMTP, NTP, DHCP, DNS, PPPOE, DDNS, FTP, IP Filter, QoS, Bonjour
Compatibility: ONVIF,PSIA,CGI
Max. User Access :20users
Smart Phone: iPhone, iPad, Android
Auxiliary Interface
RS485:N/A
Alarm:N/A
PIR Sensor Range:N/A
General
Power Supply: DC12V, PoE (802.3af)
Power Consumption:Max 3.6W
Ingress Protection: IP67
Dimensions :Φ157mm×138mm
Weight: 660g
