Camera
Image Sensor: 1/2.9" 6Megapixel progressive scan CMOS
Effective Pixels: 3072(H) x 2048(V)
Scanning System: Progressive
Electronic Shutter Speed: Auto/Manual, 1/3~1/100000s
Minimum Illumination: 0.002Lux( Color)/0.0002( black/white)/0Lux(IR on)
S/N Ratio: More than 56dB
Max. IR LEDs Length:60m
IR LEDs: 2
Ingress Protection: IP67,IK10

Lens
Lens Type: Motorized Zoom,Auto focus
Mount Type: Board-in
Focal Length: 2.7~13.5mm
Max. Aperture: F1.6~3.13
Angle of View: H: 104.2°~27.7°
Focus Control: Auto Focus in IE web
Close Focus Distance: 0.3m

Intelligence
IVS: Tripwire, Intrusion, Object Abandoned/Missing

Video
Compression: H.265/H.264/MJPEG
Streaming Capability: 3 Streams
Resolution:6MP(3072 x2048),4MP(2560×1440),20fps3M(2048×1536),25/30fps1080P(1920× 1080)
Bit Rate: H.264:32K~10240Kbps H.265:12K~9984Kbps
Day/Night: Auto(ICR) / Color / B/W
BLC Mode: BLC / HLC / WDR(120dB)
White Balance: Auto/Natural/Street Lamp/Outdoor/Manual
Noise Reduction: 3D DNR

Audio
Compression: G.711a/ G.711Mu/ AAC/ G.726
MIC: 1 Built in MIC

Network
Ethernet: RJ-45 (10/100Base-T)
Protocol:
1.HTTP; TCP; ARP; RTSP; RTP; UDP; SMTP;
2.FTP; DHCP; DNS; DDNS; PPPOE; IPv4/v6; QoS;
3.UPnP;NTP;IGMP; SNMP
Interoperability: ONVIF, PSIA, CGI;GB/T28181
Max. User Access: 10 Users /20 Users
Edge Storage: NAS;FTP;128G Micro SD memory / Local PC for instant recording
Web Viewer: IE
Management Software: Smart PSS, GDMSS,IDMSS, Easy4ip

Electrical
Power Supply: DC12V, PoE (802.3af)(Class 0)
Power Consumption: <13.2W

Construction
Casing: Metal and Plastic
Dimensions: 186.4mm×87mm x 84.2mm
Net Weight: 0.77Kg
