Camera
Image Sensor: 1/3" 4Megapixel progressive CMOS
Effective Pixels: 2688(H)x1520(V)
Scanning System:Progressive
Electronic Shutter Speed Auto/Manual, 1/3(4)~1/10000s Min. Illumination:0.01Lux/F1.4(Color), 0Lux/F1.4(IR on)
S/N Ratio More than 50dB
Video Output :1 port
Camera Features
Max. IR LEDs Length:30m
Day/Night:Auto(ICR) / Color / B/W
Backlight Compensation BLC / HLC / DWDR White Balance Auto/Manual
Gain Control:Auto/Manual
Noise Reduction:3D
Privacy Masking:Up to 4 areas
Lens
Focal Length: 2.7-12mm VF motorized lens
Max Aperture: F2.0(F2.0/F2.0)
Focus Control: Manual
Angle of View: H: 81°/110°/55°
Lens Type :Fixed lens
Mount Type:Board-in Type
Video
Compression:H.265;H.264;H.264H;H.264B;MJPEG Frame Rate;Main Stream
3M(1~20fps)/1080P/720P(1 ~ 25/30fps)
Sub Stream;D1/CIF(1 ~ 25/30fps)
Bit Rate：H.265: 32K ~ 4156Kbps
Audio
Compression :N/A
Interface; N/A
Network
Ethernet RJ-45 (10/100Base-T)
Protocol IPv4/IPv6, HTTP, HTTPS, SSL, TCP/IP, UDP, UPnP, ICMP, IGMP, SNMP, RTSP, RTP, SMTP, NTP, DHCP, DNS, PPPOE, DDNS, FTP, IP Filter, QoS, Bonjour Compatibility: ONVIF,PSIA,CGI
Max. User Access :20users
Smart Phone: iPhone, iPad, Android
Auxiliary Interface
Memory Slot: Memory Slot :Micro SD Max 128GB
RS485:N/A
Alarm:N/A
PIR Sensor Range:N/A
General
Power Supply: DC12V, PoE (802.3af) Power Consumption:Max 5.4W
Ingress Protection: IP67
Vandal Resistance: IK10
Dimensions : Φ122mm×89mm
Weight: 0.41kg
