Allen Tel GBNC-BHS 50-Ohm BNC Bulk Head Splice

the greenlee ninth NFS fusion splicer uses splice on connectors to terminate field fibers load the splice protector on to the field fighter load the appropriate boot onto the field fiber the field fiber must be stripped cleaned cleaved and placed into the ninth NFS on the left hand side of the splicer mount the splice on connector into the appropriate adapter in this case in LC u pc load the splice on connector and adapter into the splicer making sure the fiber lays in the v-groove and is in the center of the electrode area close the wind protective and initiate the splice when the splicing operation is complete open the wind protector and release the field fiber clamp and then the splice on connector clamp carefully position the splice protector over the fusion splice so that the splice protector makes contact with the connector place the fusion splice and protector into the heater ove
