The AmScope SW-3T13 trinocular stereo microscope head has a 1x/3x objective, a pair of 10x20mm widefield high-eyepoint eyepieces, and a single-arm boom stand. The microscope head has a 3" O-ring style mounting ring. The trinocular viewing head has an interpupillary range of 47 to 75mm, a 45-degree inclination to reduce eye and neck strain, and 360-degree rotation to enable sharing. The vertical trinocular port can be used as a C-Mount or 23mm photo port (camera sold separately). The WF10x20mm super-widefield high-eyepoint eyepieces combine with the 1x/3x objective to provide 10x and 30x magnification, and a longer working distance for inspecting large-scale specimens that require handling or repair. High-eyepoint eyepieces ease viewing for users who wear glasses, dioptric adjustment accommodates individual eye-strength differences, and eye guards ensure comfortable viewing. The optical glass lenses provide sharp images, and are fully-coated to ensure high-resolution images. A stereo microscope, sometimes called an inspection or dissection microscope, has low magnification and a long working distance that enables users to manipulate the object being inspected.
Ambient lighting illuminates the specimen, eliminating the need for power or batteries. The microscope has a 17" pillar that has an 8" vertical working distance. The 16" single-arm boom has a 24" overall length. Bilateral focus eases use for left- and right-handed users. The microscope head can be rotated on the X- and Y-axis. The solid cast-steel base is 1-3/4 x 9 x 9 inches (H x W x D, where H is height, the vertical distance from the lowest to highest point; W is width, the horizontal distance from left to right; D is depth, the horizontal distance from front to back).
| Specifications | |||||
|---|---|---|---|---|---|
| Head | Trinocular | ||||
MagnificatiAmScope SW-3T13 Trinocular Stereo Microscope, WH10x Eyepieces, 10X and 30X Magnification, 1X/3X Objective, Single-Arm Boom StandCurrent Price $323.99 Average $302.65 Min Price $279.98 Max Price $323.99 Price dynamics 7% Description The AmScope SW-3T13 trinocular stereo microscope head has a 1x/3x objective, a pair of 10x20mm widefield high-eyepoint eyepieces, and a single-arm boom stand. The microscope head has a 3" O-ring style mounting ring. The trinocular viewing head has an interpupillary range of 47 to 75mm, a 45-degree inclination to reduce eye and neck strain, and 360-degree rotation to enable sharing. The vertical trinocular port can be used as a C-Mount or 23mm photo port (camera sold separately). The WF10x20mm super-widefield high-eyepoint eyepieces combine with the 1x/3x objective to provide 10x and 30x magnification, and a longer working distance for inspecting large-scale specimens that require handling or repair. High-eyepoint eyepieces ease viewing for users who wear glasses, dioptric adjustment accommodates individual eye-strength differences, and eye guards ensure comfortable viewing. The optical glass lenses provide sharp images, and are fully-coated to ensure high-resolution images. A stereo microscope, sometimes called an inspection or dissection microscope, has low magnification and a long working distance that enables users to manipulate the object being inspected. Ambient lighting illuminates the specimen, eliminating the need for power or batteries. The microscope has a 17" pillar that has an 8" vertical working distance. The 16" single-arm boom has a 24" overall length. Bilateral focus eases use for left- and right-handed users. The microscope head can be rotated on the X- and Y-axis. The solid cast-steel base is 1-3/4 x 9 x 9 inches (H x W x D, where H is height, the vertical distance from the lowest to highest point; W is width, the horizontal distance from left to right; D is depth, the horizontal distance from front to back).
| |||||
