Each camera has been tested at least 3 times before shipment, if there is any question, please contact Honic service team first.

Please contact Honic support team for any question durning installation.

Checklist before purchasing:

1. Power supply, coaxial video cable and DVR are NOT INCLUDED but REQUIRED.

2. Default video mode: 1080P AHD mode.

3. Power on the camera, then switch to the corresponding video format that your DVR support.

4. 1080P FHD modes(TVI, AHD, CVI) do not compatible with 720P or 960P DVR.

5.  At least DC 12V 1A power adapter is required. If there is no video or IR leds is not working at night, please use DC 12V 2A( or higher) power adapter. It depends on the power cable length and quality.

6. Peel off the protective film on the lens and glass panel before installation.

Specifications:

Image sensor: 1/2.7" CMOS image sensor

Effective Pixel: 1920*1080 in FHD mode

Lens: 2.8mm-12mm manual zoom lens

Infrared LED: 14µ x 24PCS with 60-90 feet infrared distance based on environment.

Camera feature: Day/Night; Auto/Manual White Balance; Gain control; Noise Reduction; Picture adjustment; DWDR; OSD support; UTC support (FHD mode only)

Housing: Metal, IP66

IR-cut filter: Yes

Power Source: DC12V±10%; 1000mA

Operation Temperature: 14F-122F, RH95% Max
