Description
Camera
Effective Pixels:1920(H) x 1080(V), 2 Megapixels
RAM/ROM:1024M/128M
Scanning System:Progressive
Electronic Shutter Speed:1/1s~1/30,000s
Minimum Illumination:Color: 0.005Lux@F1.6; B/W: 0.0005Lux@F1.6
S/N Ratio:More than 55dB
IR :N/A
Lens
Focal Length:5.3mm~64mm
Max. Aperture:F1.6 ~ F4.4
Angle of View:H: 58.2° ~ 4.8°
Optical Zoom:12x
Focus Control:Auto/Manual
Close Focus Distance:100mm~ 1000mm
PTZ
Pan/Tilt Range :Pan: Pan: 0° ~ 360° endless; Tilt: -2° ~ 90°,auto flip 180°
Manual Control Speed : Pan: 0.1° ~300° /s; Tilt: 0.1° ~120° /s
Preset Speed:Pan: 300° /s; Tilt: 200° /s
Presets:300
PTZ Mode:5 Pattern, 8 Tour, Auto Pan ,Auto Scan
Speed Setup:Human-oriented focal Length/ speed adaptation
Power up Action:Auto restore to previous PTZ and lens status after power failure
Idle Motion:Activate Preset/ Scan/ Tour/ Pattern if there is no command in the specified period
Protocol:DH-SD
Intelligence
Event Trigger:Motion detection, Video tampering, Network disconnection, IP address conflict, Illegal access, Storage anomaly
Auto Tracking:N/A
IVS:Tripwire, Intrusion,Abandoned/Missing
Advanced Intelligent Functions:Face Detection
Network
Ethernet:RJ-45 (10XBase-T/100Base-TX)
Protocol :
IPv4/IPv6, HTTP, HTTPS, SSL, TCP/IP, UDP, UPnP, ICMP, IGMP, SNMP, RTSP, RTP, SMTP, NTP, DHCP, DNS,PPPOE,DDNS,FTP, IP Filter,QoS,Bonjour,802.1x
Interoperability:ONVIF Profile S&G, API
Streaming Method:Unicast / Multicast
Max. User Access:20 Users
Edge Storage :NAS (Network Attached Storage), Local PC for instant recording, Micro SD card 256GB
Web Viewer:IE, Chrome, Firefox, Safari
Management Software:Smart PSS, DSS
Smart Phone:IOS, Android
Electrical
Power Supply:AC 24V/1.5A(±10%), PoE+(802.3at)
Power Consumption:12W
