Mono Channel Kit for LM3886TF LM3886 Amp NE5532 Amplifier Parts 60W

[Music] hey guys welcome to another circuit basics video tutorial today I'm gonna be talking about the lm386 amplifier I built first I'll show you the schematic and explain what the components in the circuit do then I'll show you a PCB layout I designed and give you tips for how to layout an amplifier PCB at the end I'll wire up the amp and play some music for you guys so you can hear how it sounds now this isn't meant to be a complete tutorial I had to leave out some of the details to keep the video a reasonable length it's more of a supplement to a full tutorial I wrote on the circuit basics blog the full tutorial has all the formulas and calculations to tune the amp and all the wiring diagrams and schematics it's got pretty much everything you need to build the and except for the power supply there's a link to them in the description so be sure to check that out after the video I put
