camera
Image Sensor: 1/2.8" STARVIS CMOS
Effective Pixels: 1920(H) x 1080(V), 2 Megapixels
Electronic Shutter Speed: 1/1s~1/30,000s
Scanning System: Progressive
Minimum Illumination: Color: 0.005Lux@F1.6;0Lux@F1.6 (IR on)
S/N Ratio: More than 50dB
IR Distance: Distance up to 100m (328ft)
IR On/Off Control: Auto/ Manual
IR LEDs: 6
lens
Focal Length : 4.8mm~120mm
Max.Aperture: F1.6 ~ F4.4
Angle of View : H: 59.2° ~ 2.4°
Optical Zoom : 25x
Focus Control : Auto/Manual
Close Focus Distance : 100mm~ 1000mm
PTZ
Pan/Tilt Range:Pan:0˚~360˚; Tilt:-15˚~90˚; auto flip 180°
Manual Control Speed : Pan: 0.1° ~200° /s; Tilt: 0.1° ~120° /s
PresetSpeed : Pan: 240° /s; Tilt: 200° /s
Presets : 300
PTZ Mode : 5 Pattern, 8 Tour, Auto Pan ,Auto Scan
Video
Compression:H.265+/H.265/H.264+/ H.264
Streaming Capability:3 Streams
Bit Rate Control: CBR/VBR
Bit Rate: H.265/H.264: 448K ~ 8192Kbps
Noise Reduction: Ultra DNR (2D/3D)
Defog : Support
Digital Zoom : 16x
Flip : 180°
Privacy Masking : Up to 24 areas
Audio
Compression : G.711a/G.711Mu/G.726/AAC
Environmental
Operating Conditions : -40°C ~ 70°C (-40°F ~+158°F) / Less than 95% RH
Ingress Protection : IP66
Construction
Casing: Metal
Dimensions:Φ160mm×295mm
Net Weight:3Kg (6.61lb)
Gross Weight: 4.2Kg (9.26lb)
