Camera
Image Sensor:1/3" 3Megapixel progressive CMOS
Effective Pixels:2304(H) x1536(V)
RAM/ROM:256MB/16MB
Scanning System:Progressive
Minimum Illumination:0.78Lux/F2.0(Color), 0Lux/F2.0(IR on)
S/N Ratio:More than 50dB
IR Distance:Distance up to 10m(33ft)
IR On/Off Control:Auto/ Manual
IR LEDs:2
Lens
Lens Type:Fixed
Mount Type:Board-in
Focal Length:3.6mm
Max. Aperture:F2.0
Angle of View:H:77°;V:42°
Focus Control:Fixed
Close Focus Distance:N/A
PTZ
Pan/Tilt Range:Pan:0° ~355 ° ;Tilt:0° ~90° ;Rotation:0° ~355°
Video
Compression:H.264/H.264B/H.264H/MJPEG
Streaming Capability:2 Streams
Bit Rate Control:CBR/VBR
Bit Rate:H264:32K ~ 10240Kbps
Day/Night:Auto(ICR) / Color / B/W
BLC Mode:BLC / HLC / DWDR
White Balance:Auto/Natural/Street Lamp/Outdoor/Manual
Gain Control:Auto/Manual
Noise Reduction:3D DNR
Motion Detetion:Off / On (4 Zone, Rectangle)
Region of Interest:Off / On (4 Zone)
Electronic Image:Support
Smart IR:Support
Digital Zoom:16x
Flip:0°/90°/180°/270°
Mirror:Off / On
Audio
Compression:G.711A;G.711Mu;AAC
Network
Ethernet:RJ-45 (10/100Base-T)
Wi-Fi:Wi-Fi(IEEE802.11b/g/n),50m(open field)
Interoperability:ONVIF, PSIA, CGI
Web Viewer:IE, Chrome, Firefox, Safari
Management Software:Smart PSS, DSS,Easy4ip
Smart Phone:iPhone, iPad, Android Phone
Interface
Video Interface:N/A
Audio Interface:Built-in Mic & Speaker
RS485:N/A
Alarm:N/A
Electrical
Power Supply:DC5V 2A
Power Consumption:<8.5W
Construction
Casing:Plastic
Dimensions:94.4mm x 94.4mm x 94.4mm(3.72' x3.72''x3.72'')
Net Weight:0.215Kg(0.47lb)
Gross Weight:0.575Kg(1.27lb)
