Description
Camera
Image Sensor: 1/3" 4Megapixel progressive CMOS
Effective Pixels: 2688(H)x1520(V)
Scanning System:Progressive
Electronic Shutter Speed Auto/Manual, 1/3(4)~1/10000s
Min. Illumination: 0.01Lux/F1.4(Color), 0Lux/F1.4(IR on)
S/N Ratio More than 50dB
Camera Features
Max. IR LEDs Length:50m
Day/Night: Auto(ICR) / Color / B/W
Backlight Compensation BLC/HLC/WDR
White Balance Auto/Manual
Gain Control:Auto/Manual
Noise Reduction:3D
Privacy Masking:Up to 4 areas
Lens
Focal Length:2.7mm~13.5mm Electric Zoom Lens
Max Aperture: F2.0(F2.0/F2.0)
Focus Control: Auto
Angle of View: 92 ° ~33 °
Lens Type :Fixed lens
Video
Resolution:4M(2592×1520)/3M(2304×1296)/1080P(1920×1080)/720P(1280×720)/D1(704×576/704×480) /CIF(352×288/352×240)
Compression:H.265;H.264;H.264H;H.264B;MJPEG
Main Stream:4M(1~20fps)/3M(1~25/30fps)
Sub Stream:D1/CIF(1 ~ 25/30fps)
Third Stream:720P(1-5/8fps)(WDR on)
Bit Rate：2K ~ 10Mbps
Smart Function
Video Detection:Motion Detection,Video Tamper,DefocusDetection,Face Detection
Smart detection:Tripwire,Intrusion,Abandoned/Missing,Scene Changing,Loitering Detection,Crowd Gathering Estimation,Fast-Moving,Parking Detection
Network
Ethernet RJ-45 (10/100Base-T)
Protocol: IPv4/IPv6, HTTP, HTTPS, SSL, TCP/IP, UDP, UPnP, ICMP, IGMP, SNMP, RTSP, RTP, SMTP, NTP, DHCP, DNS, PPPOE, DDNS, FTP, IP Filter, QoS, Bonjour
Compatibility: ONVIF,PSIA,CGI
Max. User Access :20users
Smart Phone: iPhone, iPad, Android
Auxiliary Interface
Memory Slot:Micro SD Max 128GB
Alarm:N/A
General
Power Supply: DC12V, PoE (802.3af)
Power Consumption:MAX 6.3W
Working Environment:-40°C~60°C, Less than 95%RH
Protection Level:IK10,IP67
Dimensions:Φ122mm×89mm
