Camera
Image Sensor:1/3" 4MP CMOS
Effective Pixels:2688(H)×1520(V)
Scanning System:Progressive
Electronic Shutter Speed:PAL:1/4s~1/100,000s;NTSC:1/3s~1/100,000s
Minimum Illumination:0.01Lux/F2.0(Color),0lux IR on
S/N Ratio:More than 56dB
IR Distance:15m
IR On/Off Control:Auto (ICR)/Color/B/W
IR LEDs:3
Language:English/Russian/Spanish Lens
Lens Type:Fixed lens / Fixed iris
Mount Type:Board-in
Focal Length:1.6mm
Max Aperture:F2.0
Angle of View:H: 185°,V:185°
Focus Control:N/A
Video
Resolution:4M(2688x1520)
Frame Rate:PAL:2688x1520@25fps;NTSC:2688x1520@30fps;
Day/Night:Auto (Electronic) / Manual
BLC Mode:BLC / HLC / WDR
WDR:120dB
Gain Control:AGC
Noise Reduction:2D/3D
White Balance:Auto / Manual
Smart IR:Auto / Manual
Network
Ethernet:RJ-45 (10/100Base-T)
Wi-Fi:Wi-Fi(IEEE802.11b,802.11g,802.11n),50m(open field),2.4G~2.4835GHZ
Protocol:HTTP;HTTPs;TCP;ARP;RTSP;RTP;UDP;SMTP;FTP;DHCP;DNS;DDNS;IPv4/v6;QoS;UPnP;NTP;Bonjour;Multicas t;ICMP;IGMP;
Interoperability:ONVIF, PSIA, CGI
Max. User Access:10 Users/20 Users
Storage:Micro SD Card 128GB
Web Viewer:IE, Firefox, Safari
Management Software:Smart PSS,gDMSS(Android),Idmss(ios),EASY4IP,Lechange
Interface
Audio Interface1 channel In;1 channel Out
Alarm1 channel Out:1 channel In;1 channel Out
Environmental
Operating Conditions:-10° C ~ +50° C / Less than 95% RH
Electrical
Power Supply:DC12V, PoE (802.3af)(Class 0)
Construction
material:Plastic and metal
Dimensions:Φ126mm x 37.7mm
Net Weight:0.3kg
Gross Weight:0.47kg
packaging
camera1
screw3
bracket1
