Description
Camera
Image Sensor:1/2.8" STARVIS? CMOS
Effective Pixels:1920(H) x 1080(V), 2 Megapixels
RAM/ROM:1024M/128M
Scanning System:Progressive
Electronic Shutter Speed:1/1s~1/30,000s
Minimum Illumination:Color: 0.005Lux@F1.6; 0Lux@F1.6 (IR on)
S/N Ratio:More than 50dB
IR Distance:Distance up to 100m (328ft)
IR On/Off Control:Auto/Manual
IR LEDs:6
Lens
Focal Length:4.8mm~120mm
Max. Aperture:F1.6 ~ F4.4
Angle of View:H: 59.2° ~ 2.4°
Optical Zoom:25x
Focus Control:Auto/Manual
Close Focus Distance:100mm~ 1000mm
PTZ
Pan/Tilt Range :Pan: 0° ~ 360° endless; Tilt: -15° ~ 90°, auto flip 180°
Manual Control Speed : Pan: 0.1° ~200° /s; Tilt: 0.1° ~120° /s
Preset Speed:Pan: 240° /s; Tilt: 200° /s
Presets:300
PTZ Mode:5 Pattern, 8 Tour, Auto Pan ,Auto Scan
Speed Setup:Human-oriented focal Length/ speed adaptation
Power up Action:Auto restore to previous PTZ and lens status after power failure
Idle Motion:Activate Preset/ Scan/ Tour/ Pattern if there is no command in the specified period
Protocol:DH-SD
Intelligence
Auto Tracking:N/A
IVS:Tripwire, Intrusion,Abandoned/Missing, Face Detection
Network
Ethernet:RJ-45 (10Base-T/100Base-TX)
Protocol :
IPv4/IPv6, HTTP, HTTPS, SSL, TCP/IP, UDP/SUPPLIER (DAHUA) (IP), UPnP, ICMP, IGMP, SNMP, RTSP, RTP, SMTP, NTP, DHCP, DNS, PPPOE, DDNS, FTP, IP Filter, QoS, Bonjour, 802.1x
Interoperability:ONVIF, PSIA, CGI
Streaming Method:Unicast / Multicast
Max. User Access:20 Users
Edge Storage :NAS (Network Attached Storage),Local PC for instant recording, Micro SD card 128GB
Web Viewer:IE, Chrome, Firefox, Safari
Management Software:Smart PSS, DSS
Smart Phone:IOS, Android
Electrical
Power Supply:DC 12V/3A, PoE+(802.3at)
Power Consumption:13W,20W (IR on)
