Camera

Image Sensor:1/3" CMOS

Effective Pixels:2592(H) x 1520(V), 4 Megapixels

RAM/ROM:256M/128M

Electronic Shutter Speed:1/1s~1/30,000s

Scanning System:Progressive

Minimum Illumination:Color: 0.05Lux@F1.6; B/W: 0.005Lux@F1.6

S/N Ratio:More than 50dB

IR Distance:N/A

IR On/Off Control:N/A

IR LEDs:N/A

Lens

Focal Length:2.7mm~11mm

Max. Aperture:F1.6 ~ F2.8

Angle of View:H: 112.5° ~ 30°

Optical Zoom:4x

Focus Control:Auto/Manual

Close Focus Distance:100mm~ 1000mm

PTZ

Pan/Tilt Range :Pan: 0° ~ 355°; Tilt: 0° ~ 90°

Manual Control Speed : Pan: 0.1° ~100° /s; Tilt: 0.1° ~60° /s

Preset Speed:Pan: 100° /s; Tilt: 60° /s

Presets:300

PTZ Mode:5 Pattern, 8 Tour, Auto Pan ,Auto Scan

Speed Setup:Human-oriented focal Length/ speed adaptation

Power up Action:Auto restore to previous PTZ and lens status after power failure

Idle Motion:Activate Preset/ Scan/ Tour/ Pattern if there is no command in the specified period

Protocol:DH-SD

Intelligence

Auto Tracking:N/A

IVS:Tripwire, Intrusion,Abandoned/Missing, Face Detection

Network

Ethernet:RJ-45 (10Base-T/100Base-TX)

Wi-Fi:N/A

Protocol :

IPv4/IPv6,HTTP,HTTPS,SSL,TCP/IP, UDP,UPnP,ICMP,IGMP,SNMP,RTSP,RTP, SMTP, NTP,DHCP, DNS,PPPOE,DDNS,FTP, IP Filter,QoS,Bonjour,802.1x

Interoperability:ONVIF, PSIA, CGI

Streaming Method:Unicast / Multicast

Max. User Access:20 Users

Edge Storage :NAS (Network Attached Storage),Local PC for instant recording, Micro SD card 128GB

Web Viewer:IE, Chrome, Firefox, Safari

Management Software:Smart PSS, DSS

Smart Phone:IOS, Android

Electrical

Power Supply:DC 12V/1.5A, PoE(802.3af)

Power Consumption:10W
