Description
1.Camera
Image Sensor: 1/3" Progressive Scan CMOS
Min. Illumination: 0.01 Lux @ (F1.2, AGC ON)
0.04 Lux @ (F2.3, AGC ON)
Shutter time: 1s ~ 1/100,000s
Lens: 3.7mm @F2.3, angle of view: 63 °
Lens Mount: M12
Day& Night: Electronic
Wide Dynamic Range: 120 dB
Digital noise reduction: 3D DNR
2.Compression
Standard Video Compression: H.264 / MPEG4 / MJPEG
Bit Rate: 32 Kbps ~ 16 Mbps
Audio Compression: G.711/G.726/MP2L2
Triple Streams: Yes
3.Image
Max. Image Resolution: 1280x960
Frame Rate: 50Hz: 25fps (1280 × 960), 25fps (1280 × 720)
60Hz: 30fps (1280 × 960), 30fps (1280 × 720)
Third Stream: 50Hz: 25fps (1280 × 960)
60Hz: 30fps (1280 × 960)
Image Settings: Rotate mode, Saturation, Brightness, Contrast adjustable by client software or web browser
BLC: Yes, zone configurable
HLC: Support
ROI: Max. 4 ROI areas
Picture Overlay: 128 x 128, BMP 24bit, zone configurable
4.Network
Network Storage: NAS
Alarm Trigger: Intrusion detection, Defocus detection, Motion detection, Face detection, Dynamic analysis, Tampering alarm, Network disconnect, IP address conflict, Storage exception
Protocols: TCP/IP,ICMP,HTTP,HTTPS,FTP,DHCP,DNS,DDNS,RTP,RTSP,RTCP,
PPPoE,NTP,UPnP,SMTP,SNMP,IGMP,802.1X,QoS,IPv6,Bonjour
Security: User Authentication, Watermark, IP address filtering, anonymous access
System Compatibility: ONVIF, PSIA, CGI, ISAPI
5.Interface
Audio Input: 1-ch 3.5 mm audio interface, MIC IN/LINE IN
Audio Output: 1-ch 3.5mm audio interface (line level, 600 O)
Communication Interface: 1 RJ45 10M/100M Ethernet interface/1 RS232
