Camera
Image Sensor: 1/2.8" Progressive Scan CMOS
Signal System:PAL/NTSC
Min. Illumination:Color: 0.005 lux @(F1.2, AGCON), 0 lux with IR
Lens:2.8 mm, horizontal field of view: 98°
Day& Night:IR cut filter with auto switch
Wide Dynamic Range:120 dB
Digital noise reduction:3D DNR
Compression Standard
Video Compression:H.265+/H.265/H.264+/H.264/MJPEG
Video bit rate:32Kbps~16Mbps
Triple Streams:Yes
Max. Image Resolution: 1920 x 1080
Image Enhancement:BLC/3D DNR
ROI:Support 1 fixed region for each streamand sub stream separately
Network
Protocols:TCP/IP, UDP, ICMP, HTTP, HTTPS, FTP,DHCP, DNS, DDNS, RTP, RTSP, RTCP, PPPoE, NTP, UPnP, SMTP, SNMP, IGMP, 802.1X,QoS, IPv6
System Compatibility:ONVIF (Profile S, Profile G),ISAPI
Interface
Communication Interface:1 RJ45 10M / 100M Ethernetinterface
On-board storage:Built-in Micro SD/SDHC/SDXC slot,up to 128 GB
Smart Feature-set
Behavior Analysis:Line crossing detection,Intrusion detection, Unattended baggage detection, Object removal detection
Intrusion Detection:Enter and loiter in apre-defined virtual region
Unattended Baggage:Objects left over in thepre-defined region such as the baggage, purse, dangerous materials
Object Removal:Objects removed from thepre-defined region, such as the exhibits on display.
General
Dimensions: Camera: Φ111×82.4 mm (Φ4.4″×3.2″)
Package:134×134×108 mm (5.27″×5.27″×4.25″)
Weight: Camera: 500 g (1.1 lb.)
