Camera
Image Sensor: 1/2.5" Progressive Scan CMOS
Signal System: PAL/NTSC
Min. Illumination: Color: 0.008 lux @(F1.2, AGC ON), 0 lux with IR Color: 0.014 lux @(F1.6, AGC ON), 0 lux with IR
Lens: 2.8 mm, horizontal FOV: 109°, vertical FOV: 60°, diagonal FOV: 131°
Video Compression: H.265+/H.265/H.264+/H.264/MJPEG
Video bitrate: 32Kbps~16Mbps
Audio Compression: G.711/G.722.1/G.726/MP2L2/PCM
Max. Image Resolution: 2688 × 1520
Frame Rate: 50Hz: 25 fps (2688 × 1520, 2304 × 1296, 1920 × 1080) 60Hz: 30 fps (2688 × 1520, 2304 × 1296, 1920 × 1080)
Image Enhancement: BLC/3D DNR/ROI/HLC
Image Settings: Rotate mode, saturation, brightness, contrast, sharpness and white balance adjustable by client software or web browser
ROI: Support 1 fixed region for the main stream and sub-stream separately
Day/Night Switch: Day/Night/Auto/Schedule/Triggered by Alarm In
Network
Alarm Trigger: Motion detection, video tampering alarm, network disconnected, IP address conflict, illegal login, HDD full, HDD error
Protocols: TCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, PPPoE, NTP, UPnP, SMTP, SNMP,IGMP, 802.1X, QoS, IPv6, Bonjour
System Compatibility: ONVIF (Profile S, Profile G), ISAPI
Audio/Alarm: 1 input, 1 output
Communication Interface: 1 RJ45 10M / 100M Ethernet interface
On-board storage: Built-in Micro SD/SDHC/SDXC slot, up to 128 GB
Smart Feature-set
Behavior Analysis: Line crossing detection, Intrusion detection, Unattended baggage detection, Object removal detection
Exception Detections: Scene change detection
Recognition: Face Detection
