Camera

Image Sensor:|1/3" Progressive Scan CMOS

Min. Illumination:0.01Lux @ (F1.2, AGC ON) ,0 Lux with IR

Lens:2.8mm

Lens Mount:M12

Adjustment Range:Pan: 0° ~ 355°, Tilt: 0° ~ 75°, Rotation: 0° ~ 355°

Day& Night:IR cut filter with auto switch

Wide Dynamic Range:120 dB

Digital noise reduction:3D DNR

Compression Standard

Video Compression:H.264/MJPEG/H.264+

H.264 code profile:Main Profile

Video bit rate:32Kbps~16Mbps

Dual Stream:Yes


Max. Image Resolution:2688 × 1520

Image Settings:Rotate Mode, Saturation, Brightness, Contrast, Sharpness

adjustable by client software or web browser

BLC:Yes, zone configurable

ROI:Support

Network

Network Storage: NAS (Support NFS,SMB/CIFS), ANR

Alarm Trigger: Face Detection,Line Crossing, Intrusion Detection, Motion detection, Dynamic analysis, Tampering alarm, Network disconnect , IP address conflict, Storage exception

General Function: One-key reset, Anti-Flicker, heartbeat, mirror, password protection, privacy mask, Watermark, IP address filtering

System Compatibility: ONVIF (Profile S, Profile G),ISAPI Interface

Audio: 1-ch 3.5 mm audio in (Mic in/Line in)/out interface (-S model)

Communication Interface: 1 RJ45 10M / 100M Ethernet interface

Alarm: 1x alarm I/O *only for -S models

On-board storage: Built-in Micro SD/SDHC/SDXC slot, up to 128 GB

Reset Button: Yes

General

Operating Conditions:-30 °C ~ 60 °C (-22 °F ~ 140 °F)

Power Supply: 12 VDC ± 25%, PoE (802.3af Class3)

Power Consumption: Max. 5W

Impact Protection: IK10

Weather Proof: IP67

IR Range: Up to 30m

Dimensions:Φ111 × 82 (4.4" × 3.2)
