Camera
Image Sensor:1/2.9" Progressive Scan CMOS
Signal System:PAL/NTSC
Lens: 2.8 mm: Horizontal field of view: 97°, Vertical field of view: 54°, Diagonal field of view: 113°
Day& Night:IR cut filter with auto switch
Compression Standard
Video Compression: H.265+/H.265/H.264+/H.264/MJPEG
Video bit rate: 32Kbps~16Mbps
Max. Image Resolution: 2944 × 1656
Image Enhancement: BLC/3D DNR/BLC
ROI: Support 1 fixed region for main stream and sub-stream separately
Day/Night Switch: Day/Night/Auto/Schedule/Triggered by Alarm In
Network
Protocols: TCP/IP, UDP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, PPPoE, NTP, UPnP, SMTP, SNMP, IGMP, 802.1X, QoS, IPv6
General Function: One-key reset, Anti-Flicker, heartbeat, mirror, password protection, privacy mask, Watermark, IP address filtering
System Compatibility: ONVIF (Profile S, Profile G), ISAPI
Interface
Audio:2 Inputs: line in or mic in (built-in microphone), 1 output: line out, mono sound, terminal block
Communication Interface: 1 RJ45 10M / 100M Ethernet interface
> Audio
Environment Noise Filtering: Support
Audio Sampling Rate: 8 kHz/16 kHz/32 kHz/44.1 kH
Smart Feature-set
Line Crossing Detection: Cross a pre-defined virtual line
Intrusion Detection: Enter and loiter in a pre-defined virtual region
Unattended Baggage: Objects left over in the pre-defined region such as the baggage, purse, dangerous materials
Exception Detections: Scene change detection
Recognition: Face Detection
General
Operating Conditions:-30 °C ~ 60 °C (-22 °F ~ 140 °F) Humidity 95% or less (non-condensing)
Power Supply:12 VDC ± 25%, PoE (802.3af Class3)
IR Range:Up to 10m
