Camera
image Sensor: 1/2.9" Progressive Scan CMOS
Shutter time: 1/3 s to 1/100,000 s
Signal System:PAL/NTSC
Slow shutter: Support
Lens:4 mm, horizontal FOV: 78°, vertical FOV: 50°, diagonal FOV: 97°
Lens Mount: M12
Day& Night: IR cut filter with auto switch
Triple Streams: Yes
Focus:Fixed
Wide Dynamic Range:120 dB

Compression Standard
Video Compression:H.265+/H.265/H.264+/H.264/MJPEG
Video bit rate:256Kbps~16Mbps
Triple Streams:Yes

Max. Image Resolution:3072 x 2048
Frame Rate:50Hz: 20 fps (3072 × 2048, 3072 × 1728, 2944 × 1656), 25 fps (2560 × 1440, 1920 × 1080, 1280 × 720) 60Hz: 20 fps (3072 × 2048, 3072 × 1728, 2944 × 1656), 30fps (2560 × 1440, 1920 × 1080, 1280 × 720)
Image Enhancement:BLC/3D DNR/ROI/HLC
Image Settings:Rotate mode, saturation, brightness, contrast, sharpness and white balance adjustable by client software or web browser
ROI:1 fixed region for main stream and sub-stream

Network
Network Storage:microSD/SDHC/SDXC card (128G), local storage and NAS (NFS,SMB/CIFS), ANR
Alarm Trigger:Motion detection, video tampering alarm, network disconnected, IP address conflict, illegal login, HDD full, HDD error
General Function:One-key reset, Anti-Flicker, heartbeat, mirror, password protection, privacy mask, Watermark, IP address filtering
System Compatibility:ONVIF (Profile S, Profile G),ISAPI

Interface
Communication Interface:1 RJ45 10M / 100M Ethernet interface
On-board storage:Built-in Micro SD/SDHC/SDXC slot, up to 128 GB
Reset Button:Yes

General
Power Supply:12 VDC ± 25%, PoE (802.3af Class3)
Power Consumption:12 VDC, 0.6 A, max. 7.5W PoE: (802.3af, 36V to 57V), 0.3 A to 0.2 A, max. 9W
