Camera
Image Sensor:1/2" Progressive Scan CMOS
Signal System:PAL/NTSC
Min. Illumination:Color: 0.008 Lux @ (F1.2, AGC ON), 0.016 Lux @ (F1.6, AGC ON)
Shutter time:1/3 s to 1/100,000 s
Slow shutter:Support
Lens:2.8 mm, horizontal FOV: 102°
Lens Mount:M16
Day& Night:IR Cut Filter
Wide Dynamic Range:120 dB
Digital noise reduction:3D DNR
Focus:Fixed
Compression Standard
Video Compression:H.265+/H.265/H.264+/H.264/MJPEG
Video bit rate:32Kbps~16Mbps
Triple Streams:Yes

Max. Image Resolution:3840 × 2160
Frame Rate: 20 fps (3840 × 2160), 30fps (3072 × 1728)
Image Enhancement:BLC/3D DNR/HLC
Image Settings:Rotate mode, saturation, brightness, contrast, sharpness and white balance adjustable by client software or web browser
ROI:Support 1 fixed region for main stream and sub stream separately
Day/Night Switch:Day/Night/Auto/Schedule Network Network Storage:microSD/SDHC/SDXC card (128G), local storage and NAS (NFS,SMB/CIFS), ANR
Protocols:TCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, PPPoE, NTP, UPnP, SMTP, SNMP, IGMP, 802.1X, QoS, IPv6, UDP, Bonjour
General Function:One-key recovery, Anti-Flicker, three streams, heartbeat, mirror, password protection, video mask, Watermark, IP address filtering
System Compatibility:ONVIF (Profile S, Profile G), ISAPI

Interface
Communication Interface:1 RJ45 10M / 100M Ethernet interface
On-board storage:Built-in Micro SD/SDHC/SDXC slot, up to 128 GB
Reset Button:Yes
Smart Feature-set
Behavior Analysis:Line crossing detection, Intrusion detection, Unattended baggage detection, Object removal detection
Recognition:Face Detection

General
Power Supply:12 VDC ± 25%, 5.5 mm coaxial power plug ,PoE (802.3af, class 3)
