Camera
Image Sensor:1/3" Progressive Scan CMOS
Signal System:PAL/NTSC
Min. Illumination:Color: 0.01 Lux @ (F1.2, AGC ON), 0.018 lux @(F1.6, AGC ON), 0 lux with IR
Lens: 2.8 mm
Day& Night:IR Cut Filter
Wide Dynamic Range:120 dB
Digital noise reduction:3D DNR

Compression Standard
Video Compression:H.265+/H.265/H.264+/H.264/MJPEG
Video bit rate:256Kbps~16Mbps
Audio Compression:G.711/G.722.1/G.726/MP2L2/PCM
Triple Streams:Yes

Max. Image Resolution:2688 × 1520
Frame Rate:50Hz: 25fps (2688×1520, 2560×1440, 2304×1296, 1920×1080) 60Hz: 30fps (2688×1520, 2560×1440, 2304×1296, 1920×1080)
Image Enhancement:BLC/3D DNR/ROI/HLC
ROI:Support 1 fixed region for main stream and sub-stream separately

Network
Alarm Trigger:Motion detection, video tampering alarm, network disconnected, IP address conflict, illegal login, HDD full, HDD error
Protocols:TCP/IP, UDP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, PPPoE, NTP, UPnP, SMTP, SNMP, IGMP, 802.1X, QoS, IPv6
System Compatibility:ONVIF (Profile S, Profile G), ISAPI

Interface
Audio：2 Inputs: line in or mic in (built-in microphone), 1 output: line out, mono sound, terminal block
Communication Interface: 1 RJ45 10M / 100M Ethernet interface
Alarm:1 Input: Alarm in, 1 Output: Alarm out (max. 12 VDC, 30 mA), terminal block
On-board storage: Built-in Micro SD/SDHC/SDXC slot, up to 128 GB
Reset Button:Yes
Environment Noise Filtering:Support
Recognition:Face Detectionv

General
Operating Conditions:-30 °C ~ 60 °C (-22 °F ~ 140 °F)
Power Supply:12 VDC ± 25%, PoE (802.3af Class3)
IR Range:Up to 10m
Dimensions:Φ110 mm × 56.4 mm (Φ4.3" × 2.2")
Weight:Camera: Approx. 400 g (0.9 lb.)
