Camera
Image Sensor:|1/3" Progressive Scan CMOS
Min. Illumination:|Color: 0.028 lux @ (ƒ/2.0, AGC on); B/W: 0 lux with IR
Shutter time:|1/3 s to 1/10,000 s
Lens:|2.8 mm; angle of view: 106°
Lens Mount:|M12
Day& Night:|IR cut filter with auto switch

Compression Standard
Video Compression:|H.264/MJPEG
Video bit rate:|32Kbps~16Mbps
Audio Compression:|G.711/G.722.1/G.726/MP2L2

Max. Image Resolution:|2688×1520
Frame Rate:|20 fps (2688 × 1520), 30 fps (1920 × 1080), 30 fps (1280 × 720)

Network
Network Storage:|NAS (Support NFS,SMB/CIFS), ANR
Protocols:|TCP/IP, UDP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, PPPoE, NTP, UPnP, SMTP, SNMP, IGMP,802.1X, QoS, IPv6, Bonjour
Security:|User Authentication, Watermark, IP address filtering, anonymous access, flickerless, heartbeat, video mask
System Compatibility:|ONVIF, PSIA, CGI, ISAPI
On-board storage:|Built-in Micro SD/SDHC/SDXC slot, up to 128 GB

Smart Feature-set
Line Crossing Detection:|Cross a pre-defined virtual line
Intrusion Detection:|Enter and loiter in a pre-defined virtual region

General
Operating Conditions:|-30 °C ~ 60 °C (-22 °F ~ 140 °F) Humidity 95% or less (non-condensing)
Power Supply:|12 VDC ± 10%, PoE (802.3af)
Power Consumption:|Maximum 5 W
Impact Protection:|IK10
Weather Proof:|IP66
IR Range:|30 meters
Dimensions:|Φ111 mm × 82 mm (4.4" × 3.2")
Weight:|500 g (1.1 lbs)
