Camera
Signal System:PAL/NTSC
Shutter time:1/3 s to 1/100,000 s
Slow shutter:Support
Lens:horizontal FOV: 104° to 29°,vertical FOV: 55° to 17°,diagonal FOV: 125° to 34°
Lens Mount:φ14
Adjustment Range:Pan: 0° to 360°, tilt: 0° to 90°, rotate: 0° to 360°
Day& Night:IR cut filter with auto switch
Digital noise reduction:3D DNR
Focus:Auto
Compression Standard
Video bit rate:256Kbps~16Mbps
Audio Compression:G.711/G.722.1/G.726/MP2L2/PCM
Audio bit rate:64Kbps(G.711)/16Kbps(G.722.1)/16Kbps(G.726)/32-192Kbps(MP2L2)
Triple Streams:Yes
Image Settings:Rotate mode, saturation, brightness, contrast, sharpness and white balance adjustable by client software or web browser
Target Cropping:No
ROI:1 fixed region for main stream and sub-stream
Day/Night Switch:Day/Night/Auto/Schedule/Triggered by alarm in
Network
Alarm Trigger:Motion detection, video tampering alarm, network disconnected, IP address conflict, illegal login, HDD full, HDD error
Protocols:TCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, PPPoE, NTP, UPnP?, SMTP, SNMP, IGMP, 802.1X, QoS, IPv6, Bonjour
General Function:One-key reset, Anti-Flicker, heartbeat, mirror, password protection, privacy mask, Watermark, IP address filtering System Compatibility:ONVIF (Profile S, Profile G),ISAPI
General
Operating Conditions:-30 °C ~ 60 °C (-22 °F ~ 140 °F),Humidity 95% or less (non-condensing)
Power Supply:12 VDC ± 25%, PoE (802.3af Class3)
Power Consumption:12 VDC, 1.2A, max. 14.5W,PoE (802.3at, 42.5V to 57V), 0.43A to 0.3A, max. 18W
Impact Protection:IK10
Weather Proof:IP67
Dimensions: 6.0" × 5.2"
Weight:2.9lb.
