Description
Image Sensor 1/3" Progressive Scan CMOS, Min. Illumination 0.1 Lux @ (F1.2, AGC ON) -I: 0.1 Lux @ (F1.2, AGC ON), 0 Lux with IR, Shutter Time 1/25 s to 1/100,000 s Lens 2.7 - 9 mm @ F1.2 Angle of view: 101° - 30.4° Lens Mount Φ 14 Auto Iris DC drive Angle Adjustment Pan: 0° - 360°, Tilt: 0° - 75°, Rotation: 0° - 360° Day & Night Electronic (-I: IR cut filter with auto switch) Wide Dynamic Range 120Db Compression Standard Video Compression H.264 / MJPEG Bit Rate 32 Kbps - 16 Mbps Audio Compression G.711 (G.722.1 optional) Dual Stream Yes Max. Image Resolution 1920 x 1080 Frame Rate 50 Hz: 25 fps (1920 × 1080), 25 fps (1280 × 720) 60 Hz: 30 fps (1920 × 1080), 30 fps (1280 × 720) Image Setting Saturation, Brightness, Contrast adjustable through client software or web browser Network Local Storage Built-in SD/SDHC slot, up to 32 GB Network Storage NAS (iSCSI optional) Alarm Trigger Motion detection, Network disconnect , IP address conflict, Storage exception Protocols TCP/IP, HTTP, DHCP, DNS, DDNS, RTP/RTSP, PPPoE, SMTP, NTP (SNMP, HTTPS, SIP, FTP, SRTP, 802.1x, IPv6 optional) Security Password protection, Watermark System Compatibility ONVIF, PSIA, CGI Interface Audio Input 1-ch microphone input, 3.5 mm mini-jack Audio Output 1-ch 3.5 mm audio interface (Line level, 600 Ω) Communication Interface 1 RJ45 10 M/100 M Ethernet port and 1 RS-485 interface Alarm Input 2 Alarm Output 2 Video Output 1Vp-p composite output (75 Ω/RCA) Reset Button Yes General Operating Conditions -10 °C - 60 °C (14 °F - 140 °F) Conditions Humidity 90% or less (non-condensing) Power Supply 12 V DC ± 10% PoE (802.3af) Power Consumption Max. 5.5 W -I: Max. 7 W (Max. 7.5 W with IR cut filter on) Impact Protection IEC60068-2-75Eh, 50J; EN50102, up to IK10 IR Range -I: approx 10 to 20 meters Dimension Φ 140 × 114 mm (Φ 5.51" × 4.49") Weight 1400 g (3.09 lbs)
