Camera
Image Sensor: | 1/3" Progressive Scan CMOS
Min. Illumination: | Color: 0.028 lux @ (ƒ/2.0, AGC on), B/W: 0 lux with IR
Shutter time: | 1/3 s to 1/10,000 s
Lens: | Fixed, 2.8 mm (angle of view: 106° (2.8 mm)
Lens Mount: | M12
Adjustment Range: | Pan: 0° to 360°, tilt: 0° to 75°, rotation: 0° to 360°
Day& Night: | IR cut filter with auto switch
Wide Dynamic Range: | 120 dB
Digital noise reduction: | 3D DNR
Compression Standard
Video Compression: | H.264/MJPEG/H.264+
H.264 code profile: | Main Profile
Video bit rate: | 32Kbps~16Mbps
Dual Stream: | Yes
Max. Image Resolution: | 2688×1520
BLC: | Yes, zone configurable
ROI: | Yes
3D DNR: | Supported
Network
Network Storage: | NAS (Support NFS,SMB/CIFS), ANR
Security: | User Authentication, Watermark, IP address filtering, Anonymous access
System Compatibility: | ONVIF, PSIA, CGI, ISAPI
Interface
Communication Interface: | 1 RJ45 10M / 100M Ethernet interface
Line Crossing Detection: | Cross a pre-defined virtual line
Intrusion Detection: | Enter and loiter in a pre-defined virtual region
General
Operating Conditions: | -30 °C ~ 60 °C (-22 °F ~ 140 °F) Humidity 95% or less (non-condensing)
Power Supply: | 12 VDC ± 10%, PoE (802.3af)
Power Consumption: | Maximum 5.5 W (maximum 7.5 W with IR cut filter on)
Weather Proof: | IP66
IR Range: | 30 meters
Dimensions: | Φ127 mm × 97.5 mm (5.0" × 3.8")
Weight: | 670 g (1.5 lbs)
