Hitachi CP-WX3042WN LCD PROJ 3000L

decide the size and position of the projection screen before hammering in the anchor bolts for the attachment fittings for the purpose of this demonstration we will be projecting an 80 inch screen measure the position of the projection screen then mark the top of the screen and the center of the screen when attaching the finger-touch unit a clearance of 50 to 100 millimetres is required between the top of the screen and the finger-touch unit a clearance space of at least 50 millimeters is required around the screen use the template provider to determine the positions of the wall holes the center line of the base fitting would be thirty four point six millimeters to the right of the centerline of the projection screen next for the WXGA model use the 610 screen table on the template to reference the position of the fitting as this is an 80 inch screen the distance between the center of th
