Camera
Sensor type: 1/2.9" 6Megapixel progressive scan CMOS
Sensor effective pixels: 3072(H) x 2048(V)
Electronic Shutter Speed: Auto/Manual, 1/3~1/100000s
Minimum Illumination: 0.002Lux( Color)/ 0.0002( black/white)/ 0Lux(IR on)
S/N Ratio: More than 56dB
Adjust the angle: Level : 0 ° ~ 360 °, Vertical : 0 ° ~ 65 °
IR Distance: Distance up to 30m(98ft)
Ingress Protection : IP67 Lens
Focal Length : 3.6mm
Max. Aperture: F2.2
Angle of View: 3.6mm : H: 70° V: 48°
Close Focus Distance: 1.2m
Intelligence
IVS ：Tripwire, Intrusion, Object Abandoned/Missing
Advanced Intelligent Functions : Face Detection
Video
Compression : H.265/H.264/MJPEG
Streaming Capability : 3 Streams
Resolution : 50HZ:Main (3072×2048@20fps),Sub(704×576@20fps),Third(1280×720@6fps);
Main(2592×1944@25fps),Sub(704×576@25fps),Third(1280×720@4fps) 60Hz:
Main(3072×2048@20fps),Sub(704×480@20fps),Third(1280×720@7fps);
Main(2688×1520@30fps),Sub(704×480@30fps),Third(1280×720@10fps)"
Bit Rate: 14K ~ 10240Kbps
Day/Night: Auto(ICR) / Color / B/W
BLC Mode : BLC / HLC / WDR(120dB)
White Balance: Auto/Natural/Street Lamp/Outdoor/Manual
Noise Reduction : 3D DNR
Audio
Compression : G.711a/ G.711Mu/ AAC/ G.726
Audio Interface : Built-in Mic
Network
Ethernet : RJ-45 (10/100Base-T)
Protocol: HTTP; TCP; ARP; RTSP; RTP; UDP; SMTP;FTP; DHCP; DNS; DDNS; PPPOE;
IPv4/v6; QoS; UPnP;NTP;IGMP; SNMP
Interoperability : ONVIF, PSIA, CGI;GB/T28181
Max. User Access: 20 Users
Edge Storage : NAS; Local PC for instant recording
Smart Phone : IOS, Android
Electrical
Power Supply : DC12V, PoE (802.3af)(Class 0)
Power Consumption : <4.8W
Construction
Casing : Metal
Dimensions : Φ106mm×93.7mm (4.17"×3.69")
Net Weight : 0.47Kg (1.04lb)
Gross Weight : 0.65Kg (1.43lb)
