Description

Purchase Notice

1). The IP PBX is with 4 FXO ports.
2). with 2 RJ45 Ethernet Ports.
3). The software is Freepbx(distro),please understand how to config Freepbx before you buy.We don't provide support of the software.
4).Default Settings,

RJ45 Port 1 : DHCP Client
RJ45 Port 2 : 192.168.0.200
Username / Password:
root / 123456

Technical Specifications:

MB:IMI45 embedded Mini-itx ATOM motherboard
CPU: Intel Atom N2800 1.86GHz
DRAM: 2GB DDR2 SDRAM
HDD : 32G SSD
Storage:
44pin PATA connector for 2.5" Notebook Hard Drive
1 SATA slot for 2.5" Notebook SATA Hard Drive (with DC12V Power in)
Power: 20PIN ATX power supply
Expansion: 1 PCI slot, fixed and individual interrupt
Connectivity:
1 PCI-E 10/100/1000Mbps Ethernet controller (rlt8111c)
1 PCI-E 10/100Mbs Ethernet controllers(rtl8103e)
IMI45 is configured with the above 2 Ethernet Channels.
I/O: 1*DB9 serial port, for debug console usage, RS232
Rack Mountable

Key Features:

80 Concurrent calls
Up to 1000 registers
Full Feature IP PBX
Video Calls
Recording
DID(Direct Inward Dialing Number)
Call Monitoring

Basic Features:

Codec: G.711-Ulaw,G.711-Alaw,G.726,G.729,GSM,SPEEX,H.261,H.263,H.263+,H.264
Call Hold/Forward/Transfer/Waiting/Parking
Call Paging and Intercom
Caller ID
Music On Hold
DISA(Direct Inward System Access)
Flexible Dial Plan
Ring Group
Conference Room
Call Logs
BLF(Busy Lamp Field)
Configuration By web
Built-in SIP/IAX2 server
Build-in voice mail server

Sofware : Freepbx

--------------------------
