Lens
Zoom Speed:Approx. 2s (optical lens, wide-tele)
Field of View:Horizontal field of view: 100° to 33° (Wide-Tele),Vertical field of view: 53° to 18° (Wide-Tele),Diagonal field of view: 119° to 37.5° (Wide-Tele)
Minimum Working Distance:10 to 1500mm (wide-tele)
Aperture Range:F1.6 to F2.7
Pan & Tilt
Pan Range:0° to 330°
Pan Speed:Configurable, from 0.1°/s to 100°/s, Preset speed: 100°/s
Tilt Range:Tilt: 0°~90°
Tilt Speed:Configurable, from 0.1°/s to 100°/s,Preset Speed: 100°/s
Proportional Zoom:Rotation speed can be adjusted automatically according to zoom multiples
Number of Preset:300
Power-off Memory:Support

Input & Output
Audio Input:1-ch audio input
Audio Output:1-ch audio output
Network
Ethernet:10Base -T, /100Base-TX, RJ45 Connector
ROI encoding:Support 2 areas with adjustable levels
Audio Compression:G.711ulaw/G.711alaw/G.726/MP2L2/G.722
Audio Mode:OFF/Audio input/Audio output

General
Power Supply:12 VDC & PoE
Power Consumption:Max.: 12 W (Max. 3.9 W for IR)
Working Temperature/Humidity:-20°C to 60°C (-4°F to 140°F)
Protection Level:IP66 Standard, IK10, TVS 4000V Lightning Protection, Surge Protection and Voltage Transient Protection
Material:Aluminum alloy, PC, PC+ABS
Dimensions:5.15" × 4.00"
Weight:1.17 lb
