Camera
Image Sensor: 1/3" 3Megapixel progressive scan Aptina CMOS
Effective Pixels: 2048(H)x1536(V)
Scanning System: Progressive
Electronic Shutter Speed:Auto/Manual, 1/3(4)~1/10000s
Min. Illumination: 0. 01Lux/F1.4 (Color), 0Lux/F1.4(IR on)
S/N Ratio: More than 50dB
Video Output: N/A
Camera Features
Max. IR LEDs Length 70ft
Day/Night: Auto(ICR)/Color/B/W
Backlight Compensation: BLC / HLC / DWDR
White Balance: Auto/Manual
Gain Control: Auto/Manual
Noise Reduction: 3D
Privacy Masking: Up to 4 areas
Lens:
Focal Length: 2.7mm~12mm
Max Aperture: F1.4
Focus Control: Auto
Angle of View: H: 92°～28°
Lens Type: Motorized/Fixed Iris
Mount Type: Board-in Type
Video
Compression: H.264/ H.264H/ H.264B/ MJPEG
Resolution: 3M(2048×1536)/1080P(1920×1080)/1.3M(1280×960)/720P(1280×720)/D1(704×576/704×480)/CIF(352×288/352×240)
Frame Rate:
Main Stream: 3M(1 ~ 20fps)/1080P (1 ~ 25/30fps)
Sub Stream: D1/CIF(1 ~ 25/30fps)
Bit Rate: H.264: 56K ~ 6144Kbps
Audio:
Compression: N/A
Interface: N/A
Network
Ethernet: RJ-45 (10/100Base-T)
Wi-Fi: N/A
Compatibility: ONVIF, PSIA, CGI
Max. User Access: 20 users
Smart Phone:iPhone, iPad, Android, Windows Phone
General
Power Supply: DC12V, PoE (802.3af)
Power Consumption: <8.5W
Working Environment: -30°C~+60°C, Less than 95% RH
Ingress Protection: IP66
Vandal Resistance: IK10
Dimensions: φ122mm×89mm
Weight: 0.5kg
