Description
Camera
Image Sensor: 2MP CMOS Image Sensor
Signal System: PAL/NTSC
Effective Pixels: 1944(H)*1092(v)
Min. illumination: 0.01 Lux @ (F1.2,AGC ON), 0 Lux with IR
Shutter Time: 1/25s to 1/50,000s
Lens: 3.6mm
Lens Mount: M12
Day & Night: ICR
Angle Adjustment: Pan 0 - 360 degrees, Tilt 0 - 75 degrees, Rotation 0 - 360 degrees
Synchronization: Internal Synchronization
WDR: 120dB
Video Frame Rate: 1080p@25fps / 1080p@30fps
HD Video Output: 1 Analog HD Output
CVBS Output: 1Vp-p Composite Output (75ohms/BNC)
S/N Ratio: >62dB
Menu
Scene: Indoor, Outdoor, Indoor1, LOW-LIGHT
Camera ID: On/Off (15 characters, position programmable)
AGC: Support
D/N Mode: Color/BW/SMART
White Balance: ATW, AWC-SET, Manual
Privacy Mask: On/Off, maximum 8 zones
Motion Detection: On/Off, maximum 4 zones
BLC: Support
Anti-flicker: On/Off
Language: English, Japanese, CHN1, CHN2, Korean, German, French, Italian, Spanish, Polish, Russian, Portugese, Dutch, Turkish, Hebrew and Arabic
Functions: HSBLC, Digital noise reduction, Digital zoom (62x), slow shutter, Mirror, Defog, Defect pixel correction, Smart D-ZOOM
General
Power Supply: 12VDC+-15%
Power Consumption: Max. 5W
Protection Level: IP66
IR Range: Up to 40m
Communication: Up the coax, Protocol: Pelco-C (CVBS output), HIKVISION-C (TVI output)
Dimensions: 114.6mm x 89.1mm (4.5" x 3.5")
Weight: 450g
