On the input side of the SDI-PPC, you'll find two 1/4" TS jacks. These are suitable for instruments such as electric guitars, basses, and keyboards. If you're using only one of the 1/4" inputs, the other can function as a parallel output, allowing you to send the copy of the signal to an amplifier. This usage lets you split a guitar signal during recording, so you have the amped track in addition to a clean, DI'ed take to use during the mixing stage. A 3.5mm input is on hand for playing backing tracks from smartphones, tablets, and other compatible media players. Rounding out the input section are two RCA jacks for turntables, A/V connections, computer soundcards, and more. Two XLR connectors are provided for outputs.

Specs

Input Connectors: 2 x 1/4" TS inputs, phone type, 2 x RCA inputs, 1 x 3.5 mm stereo TRS input
Output Connectors: 2 x XLR outputs
Dynamic Range: 128 dB
Frequency Range: 20 Hz to 18.5 kHz
Input Impedance: 67 kOhms
Output Impedance: 600 Ohms
Maximum Output: +18 dB at 20 Hz
Signal to Noise Ratio: 100 dB
Attenuation Switch: 0, -15 dB
Power Requirements: 48 V phantom power
Dimensions (L x W x H): 5.7 x 3.4 x 1.5" / 14.5 x 8.7 x 3.8 cm
Weight: 14.3 oz / 405.4 g

Packaging Info

Package Weight: 1.15 lb
Box Dimensions (LxWxH): 6.9 x 5.8 x 2.9"
