Description
Camera
Image Sensor:1/1.8" Progressive Scan CMOS
Signal System:PAL/NTSC
Min.Illumination :0.0014 Lux @ (F1.0, AGC ON), 0 Lux with Light
Shutter time:1/3 s to 1/100,000 s
Slow shutter::Support
Lens:
4 mm,horizontal FOV: 94°, vertical FOV: 48°, diagonal FOV: 115°
Lens Mount:M16
Adjustment Range: Pan: 0° to 360°, tilt: 0° to 75°, rotate: 0° to 360°
Day& Night:Auto
Wide Dynamic Range:120 dB
Digital noise reduction: 3D DNR
Compression Standard
Video Compression:H.265+/H.265/H.264+/H.264/MJPEG
Video bit rate:32Kbps~16Mbps
Network
Network Storage:microSD/SDHC/SDXC card (128G), local storage and NAS (NFS,SMB/CIFS), ANR
Protocols:TCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, PPPoE, NTP, UPnP, SMTP, SNMP, IGMP, 802.1X, QoS, IPv6, UDP, Bonjour
General Function:One-key reset, anti-flicker, three streams, heartbeat, mirror, password protection, privacy mask, watermark, IP address filter
System Compatibility:ONVIF (Profile S, Profile G),ISAPI
Interface
Audio:1 audio input (built-in mic), mono sound(-U)
Communication Interface:1 RJ45 10M / 100M Ethernet interface
Reset Button:Yes
Smart Feature-set
Behavior Analysis:Line crossing detection, intrusion detection, unattended baggage detection, object removal detection
Line Crossing Detection: Cross a pre-defined virtual line
Intrusion Detection:Enter and loiter in a pre-defined virtual region
Unattended Baggage:Objects left over in the pre-defined region such as the baggage, purse, dangerous materials
Object Removal:Objects removed from the pre-defined region, such as the exhibits on display.
General
Power Supply:12 VDC ± 25%, 5.5 mm coaxial power plug ,PoE (802.3af, class 3)
Power Consumption:12 VDC, 0.5 A, max. 6 W ; PoE: (802.3af, 36 V to 57 V), 0.3 A to 0.1 A, max. 7.5 W
