Description
Camera
Image Sensor:1/2.8" 2Megapixel progressive scan STARVIS? CMOS
Effective Pixels:1920 (H) × 1080 (V)
RAM/ROM:512 MB/128 MB
Scanning System:Progressive
Electronic Shutter Speed:Auto/Manual, 1/3 s-1/100000 s
Minimum Illumination:0.002 Lux@F1.6
LED Distance:Distance up to 50 m (164 ft)
LED On/Off Control:Auto/Manual
IR LEDs:1 IR, 1 LED
Lens
Lens Type:Fixed
Mount Type:Board-in
Focal Length:2.8mm
Max. Aperture:F1.6
Angle of View:H: 106°, V: 57°/H: 87°, V: 46°/H: 53°, V: 30°
Optical Zoom:N/A
Aperture Type:Fixed
Close Focus Distance:0.6 m (1.97 ft)/1.2 m(3.94 ft)/2.5 m(8.20 ft)
Artificial Intelligence
Perimeter Protection :Tripwire, Intrusion (Human & Vehicle classification)
People Counting : Support Line crossing/Region/Queueing people counting; Support 4 accesses independent detection, 4 areas independent detection
Audio
Compression:G.711a, G.711Mu, G.726, AAC, G.723
Network
Ethernet:RJ-45 (10/100 Base-T)
Protocol :
HTTP, TCP, ARP, RTSP, RTP, UDP, RTCP, SMTP,FTP, DHCP, DNS, DDNS, PPPoE, IPv4/v6, SNMP, QoS,UPnP, NTP, ICMP, HTTPS, IGMP, 802.1x
Interoperability:ONVIF (Profile S/Profile G), CGI, Milstone, Genetec, P2P
Streaming Method:Unicast/Multicast
Max. User Access:20 Users
Edge Storage :
NAS
FTP
Micro SD card 256 GB
Web Viewer:IE (versions newer than IE8), Chrome,Firefox, Safari (versions newer than Safari 12)
Management Software:Smart PSS, DSS, P2P
Smart Phone:iOS, Android
Electrical
Power Supply:DC 12V (±30%), PoE (802.3af) (Class 0)
Power Consumption :<7W
