Description
CAMERA: Image Sensor: 1/3" Progressive Scan CMOS ● Min. Illumination: 0.014 lux @F2.0, AGC ON, 0 lux with IR ● Shutter time: 1/25s ~ 1/100,000s ● LENS: 4mm @F2.0 ● 2048 × 1536: angle of view: 70° ● 1920 × 1080: angle of view: 79° ● Lens Mount: M12 ● Day& Night: IR cut filter with auto switch ● Digital noise reduction: 3D DNR ● Compression Standard ● Video Compression: H.264 / MPEG4 / MJPEG ● Bit Rate: 32 Kbps ~ 16 Mbps ● IMAGE: Max. Image Resolution: 2048x1536 ● Frame Rate: 60Hz: 20fps (2048 x 1536), 30fps (1920 × 1080), 30fps (1280 × 720) ● 50Hz: 20fps (2048 x 1536), 25fps (1920 x1080), 25fps (1280 x 720) ● Image Settings: Saturation, brightness, contrast adjustable through client software or web browser ● BLC: Yes, zone configurable ● NETWORK: Network Storage: NAS (iSCSI optional) ● Alarm Trigger: Motion detection, tampering alarm, network disconnect, IP address conflict, storage exception ● Protocols: TCP/IP, HTTP, DHCP, DNS, DDNS, RTP, RTSP, PPPoE, SMTP, NTP, SNMP, HTTPS, FTP, 802.1x, Qos (SIP, SRTP, IPv6 optional) ● Security: User authentication, watermark ● System Compatibility: ONVIF, PSIA, CGI ● INTERFACE: Communication Interface: 1 RJ45 10M / 100M Ethernet interface ● GENERAL: Operating Conditions: -13°F ~ 140°F (-25°C ~ 60°C) humidity 95% or less (non-condensing) ● Power Supply: 12 VDC ± 10%, PoE (802.3af) ● Power Consumption: max. 7W ● Weather Proof: IP66 ● IR Range: Up to 100ft (30m) ● Dimensions: Φ5.0"× 3.9" (Φ127.0 x 97.5 mm) ● Weight: 1.5 lb. (670g)
