Description
Image Sensor: 1/1.8" Progressive Scan CMOS. Min. Illumination: 0.05 Lux @ (F1.2, AGC ON), 0.3 Lux @ (F2.8, AGC ON), 0 Lux with IR. Shutter Speed: 1/25 (1/30) s ~ 1/100,000s. Lens: 1.27mm, F2.8; Angle of view: 180° (wall mount), 360° (ceiling mount). Lens Mount: M12. Day & Night: IR cut filter with auto switch. DNR: 3D DNR. Wide Dynamic Range: Digital WDR. Video Compression: H.264 / MJPEG. H.264 Type: Baseline Profile / Main Profile / High Profile. Video Bit Rate: 32 Kbps ~ 16 Mbps. Network Storage: NAS (Support NFS, SMB/CIFS). Alarm Trigger: Line crossing detection, Intrusion detection, Motion detection, Dynamic analysis, Tampering alarm, Network disconnect, IP address conflict, Storage exception. Protocols: TCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, ONVIF (PROFILE S, PROFILE G), PSIA, CGI, ISAPI. Security: User Authentication, Watermark, IP address filtering, Anonymous access. Communication Interface: 1 RJ45 10M/100M/1000M Ethernet interface; 1 RS485 interface (-S). On-board Storage: Built-in Micro SD/SDHC/SDXC slot, up to 128 GB. Working Temperature/ Humidity: -22 °F - 140 °F; Humidity 95% or less (non-condensing). Power Supply: 12 VDC ± 10% / PoE (802.3af). Power Consumption: <12W. IR Range: About 50ft. Impact Protection: IEC60068-2-75Eh, 20J; EN50102, up to IK10. Ingress Protection Level: IP66. Dimensions: 6.6×1.7" (167.4×43.8mm). Weight: 1.7lb.
